DL 512 H 115 V
Product information "DL 512 H 115 V"
| Depth int.: | 240 mm |
|---|---|
| Ext. depth: | 265 mm |
| Ext. height: | 350 mm |
| Ext. width: | 325 mm |
| External dimensions (WxDxH): | 325 x 265 x 350 mm |
| Heating capacity: | 400 W |
| Height int.: | 200 mm |
| IP code: | IP 33 |
| Int. width: | 300 mm |
| Internal dimensions (WxDxH): | 300 x 240 x 200 mm |
| Manufacturer Article Number: | 7184-1 |
| Max. temperature: | 80 °C |
| Max. voltage: | 115 V |
| Min. temperature: | 20 °C |
| Nominal capacity: | 13.0 l |
| Plug type: | US |
| Power supply: | 115 V, 50/60 Hz |
| Power supply frequency: | 50/60 Hz |
| Temperature: | 20 ... 80 °C |
| Type: | DL 512 H |
| Type of auxiliary energy: | Mains connection |
| UNSPSC: | 41102929 |
| Ultrasonic frequency: | 35 kHz |
| Ultrasonic power: | 215 W |
| Weight: | 8.0 kg |
| With stopcock: | Yes |
