Universal microscope for general applications.Can easily be adapted for many applications using the wide range of accessoriesEyepieces: 10x flat eyepiecesAchromatic objectives: 4x, 10x, 40x, 100xTrinocular microscopeWith phototube for photography and video
Measurement Scales: Angle of rotation, specific rotation, International Sugar Scale, concentration, purity.Wavelength measurement at 589 nm (equivalent to the sodium-D line spectrum) and 882 nm (near infra red)Measurement stability in 13 seconds (4 seconds in the high-speed and consecutive measurement mode)Resolution of up to 3 decimal placesRepeatability of ±0.003° Angle of Rotation and ±0.009°ZUp to 999 automatic consecutive measurements followed by average value displaySleep and timer feature to take measurement later at specified timeImproved usability due to touch screen technologyConnectivity to RX Digital Refractometers for automatic purity measurementSpecificationsMeasurement range Angle of rotation: International standard sugar scale:-89.999 to +90.000° or -360 to +360° -259 to +259°Resolution Angle of rotation: International standard sugar scale: 0.001° 0.001°ZMeasurement accuracy Angle of rotation 589 / 882 nm: International standard sugar scale 589 / 882 nm: ±0.005° / ±0.010° (-45 to +45°) ±0.015°Z / ±0.0700°Z (-130 to +130°Z)Measurement temperature range:5 to 40°CObservation tubes:100mm (5ml), 200mm (10ml)Power supply:100-240V, 50/60Hz a.c.Dimensions: Weight:600 x 365 x 210mm 20kg
