Digital timer with 3 channels. The duration and volume of the acoustic alarm can be set individually for each channel.Clear LCD displayStopwatch (counting up)Short timer (counting down)Memory functionWith clock and dateAudible and visual alarmNIST-traceable calibration certificate includedScope of supply: Timer, battery, NIST-traceable calibration certificate
Licence to activate the automatic draft shield.
Licence to activate the ionizer.
DIN S-1: DIN adapter set.O DIN S-1: The open DIN spindle set measures viscosities according to DIN 53019 and can be used with customer-specific vessels. The set includes a single-wall-open-jacket to quickly dive into the sample liquid as well as a coaxial cylinder system for the analysis of the sample at a specific shear rate and shear stress is included.ELVAS-1: The extremely low viscosity adapter spindle set ELVAS-1 includes a double jacket to quickly heat up or cool down the sample as well as a coaxial cylinder system for the analysis of the sample at a specific shear rate and shear stress. This 16 ml spindle is commonly used with the ROTAVISC lo-vi and allows measurements from 1 mPas (water temperature at 20 °C). The spindle without the water jacket can also be used in customer-specific vessels.VAN-1: The vane spindle set allows the viscosity measurement of suspensions. Four vane spindles are included in the delivery.T-SP-Set: Set with 6 T spindlesSAS-1: Spiral adapter to measure the viscosity of very sticky and other viscous samples. Additionally, it is possible to analyse the fluid behavior of different shear rates.SP set-1: Standard spindle set, inculdes 4 spindles (SP1, SP2, SP3, SP4).SP set-2: Standard spindle set, inculdes 6 spindles (SP7, SP8, SP9, SP10, SP 11, SP12)
The AE2000 MET series is the ideal microscope for industrial quality inspection and material science. Different objective options allow applications in brightfield & darkfield or examination of larger samples.Infinity Optics [CCIS®]Observation Tube Siedentopf Type, Trinocular-/Phototube 45°, F.N. 20, 360° swivellingInterpupillary Distance 48-75 mmEyepieces High-Eyepoint N-WF 10x/20 mm with diopter adjustment on both eyepieces and rubber eyecupsSide facing quintuple nosepieceObjectives CCIS LM Plan achromat DIN 5X, 10X, 20X, 50XM32 with adapters to W 4/5" x 1/36" (RMS standard)Mechanical stage 280 x 192 mm surface with metal round and oval stage insertsX and Y range of 50 x 50 mmExternal lamphouse, Illumination 12 V/100 W halogen with intensity control and sleeping modeUniversal power supply 100-240 V (CE)Blue filter, Allen hexagonal key, vinyl dust cover and power cord
The BA310 MET series is the ideal microscope for industrial quality inspection or material science. Different alternative stand options also allow applications in brightfield or examination of larger samplesInfinity Optics [CCIS®]Observation Tube Trinocular 30° (Light split 100:00/20:80), F.N. 20Interpupillary distance 48-75mmWidefield high eyepoint eyepieces N-WF10X/20mm with diopter adjustment on both eyepieces and rubber eyecupsReversed quintuple revolving nosepieceCCIS LM Plan Achromatic objectives 5X, 10X, 20X, 50XCoaxial course and fine focusing systemMechanical stage, hard coated with built-in low position coaxial stage controlEpi-illuminator 12V/50W quartz halogen with integrated field and aperture diaphragms and external lamphousePower supply 100-240V (CE)Power cord, Allen hexagonal key, vinyl dust cover
The BA310 MET series is the ideal microscope for industrial quality inspection or material science. Different alternative stand options also allow applications in brightfield or examination of larger samplesInfinity Optics [CCIS®]Observation Tube Trinocular 30° (Light split 100:00/20:80), F.N. 20Interpupillary distance 48-75mmWidefield high eyepoint eyepieces N-WF10X/20mm with diopter adjustment on both eyepieces and rubber eyecupsReversed quintuple revolving nosepieceCCIS LM Plan Achromatic objectives 5X, 10X, 20X, 50XCoaxial course and fine focusing systemMechanical stage, hard coated with built-in low position coaxial stage controlEpi-illuminator 12V/50W quartz halogen with integrated field and aperture diaphragms and external lamphousePower supply 100-240V (CE)Power cord, Allen hexagonal key, vinyl dust coverCoaxial course and fine focusing system, course focusing system adjustableTransmitted illumination of 6V/30W Quartz Halogen Koehler illumination with intensity controlBlue, frosted, green and yellow filtersInterchangeable LED modul for transmitted light available
An extremely powerful yet affordable Polarization microscope for Transmitted light samples. Designed for the examination of birefringent samples from petrography and mineralogy, and can also be used for the synthetic materials in industry.Infinity Optics [CCIS®]Observation Tube Siedentopf Type, Trinocular-/Phototube 30°, F.N. 20Interpupillary Distance 55-75 mmEyepieces High-Eyepoint N-WF 10x/20 mm with dioptre adjustment on both eyepieces and rubber eyecupsRotatable analyzer 360°, Bertrand lens 0,5X and slot for compensatorsReversed quadruple revolving nosepiece, single centrable positionsObjectives CCIS® EC Plan Achromatic Strain-free 4x, 10x, 40x-S, 60x-S360° circular rotating stage, 160 mm diameter, 1° increments, 0,1°vernier scale and lockableAchromat swing-out condenser N.A. 0.90/0.13 (strain-free) with iris diaphragm and rotatable polarizerKoehler illumination quartz halogen 6V/30 W with intensity controlUniversal power supply 100-240 V (CE)Empty insertion plate, blue filter, power cord, Allen hexagonal key, vinyl dust cover and spare fuse
Alcoholmeters with an error limit of ±0.1 % vol. Temperature range from 0 to 30 °C with 0.5 °C graduation and an accuracy of ±1 °C. Blue filling. Packed in square plastic sleeve.
According to E.E. 76/765. Class II, ethanol % vol. Suitable for official testing. Reference temperature: 20 °C. With thermometer.
0 to 100 % mas / % Vol at reference temperature: +20°C.Without thermometer. With DAkkS calibration certificate and 3 checkpoints.Packed in a square plastic sleeve.
For absorbing and damping vibrations down to 16Hz. Comprises of a moulded terazzo slab supported on four vibration absorbers with non-slip feet. Suitable for isolating sensitive analytical instruments such as balances and microscopes. Will support up to 16kg.Polished surfaceResists scratches and chemical attack
Precision hydrometers acc. to ASTM E2995-14 for determination of density for mineral oil, with thermometer "mercury free".Hydrometer with thermometer, error-limit for density: ± 0,5 kg/m³, with thermometer -20 to +65°C in 1°C, blue filling, error-limit ± 1°C. With works calibration on request. With blue, environmental friendly filling of thermometers. Each item packed in plasic tubes for breakage protection.
Precision hydrometers acc. to ASTM E2995-14 for determination of density for mineral oil, with thermometer "mercury free".Hydrometer with thermometer, error-limit for density: ± 0,5 kg/m³, with thermometer -20 to +65°C in 1°C, blue filling, error-limit ± 1°C. With blue, environmental friendly filling of thermometers. Each item packed in plasic tubes for breakage protection.
Required when using the disposable combustible crucible C 14.
Accurately and reliably determining the melting point of up to three samples simultaneously.The MP-800D has a custom designed user interface based on an established Android platform for intuitive setup and navigation. All operation is via the 7" colour touchscreen. Once programmed, users can leave the MP-800D to complete the melt analysis independently, alternatively the melt can also be observed on the screen live or post melt. During post melt review additional measurement tags can be added if required, such as meniscus point or the automatically obtained result can be overwritten.A generous 8 GB on board storage is included, which should comfortably hold approximately 300 melts files including videos. Results can also be transferred via USB stick on to PC or can be printed directly from the unit via the accessory printer.The MP-800D features a useful storage drawer to house all standard capillary tubes.All units are factory supplied with a calibration certificate showing individual serial number for traceability. The SMP50 also conforms to Pharmacopeia and GLP.SpecificationsNo of samples:3 simultaneouslyTemperature range:Ambient to 400 °CTemperature resolution:0.1 °CDisplay:7'' HD ColourRamp rates:0.1 to 20 °C in 0.1 °C incrementsTemperature sensor:PT1000 Platinum resistanceMemory:8 GB (approx. 300 results with video)Cool down time:350 to 50 °C (approx. 12 min)Heat up time:50 to 350 °C (approx. 6 min)Data transfer:USB Flash driveSample level:2 to 3 mm in 50 mm or 100 mm length capillariesWeight:4.6 kgPower supply:120-230 V, 50/60 Hz
