Sub Blot Systems omniBLOT
Content:
1
Product number:
4668184
Product information "Sub Blot Systems omniBLOT"
The omniBlot is an stand-alone unit for the tank-blot method. Each unit consists of an OmniPAGE tank and lid, a electroblotting insert as well as cassettes and fibre pads. The versatile design of the tanks and the matching lids are compatible with the vertical PAGE or IEF systems with the appropriate optional inserts.
- Mini system transfers up to 4 Mini gels
- Mini Wide system transfers up to 4 Mini Wide and 8 Mini gels
- Maxi system transfers up to 4 Maxi gels, 8 Mini Wide and 16 Mini gels
- Run-times ranging between 2 and 20 hours
- Rigid cassettes eliminate the formation of shadow bands
- Colour coded cassettes prevent reverse polarity for correct orientation
- Cooling with cooling packs at high transmission intensity
| Blotting method: | Wet |
|---|---|
| Depth: | 160 mm |
| Depth gel: | 85 mm |
| Depth transfer area: | 100 mm |
| Dimensions (WxDxH): | 260 x 160 x 160 mm |
| Gel (WxD): | 160 x 85 mm |
| Height: | 160 mm |
| Manufacturer Article Number: | SB10W |
| Nominal capacity: | 2800 ml |
| Transfer area (WxD): | 200 x 100 mm |
| Transfer time: | 1 ... 2 h |
| Type: | omniBlot Mini Wide |
| Width: | 260 mm |
| Width gel: | 160 mm |
| Width transfer area: | 200 mm |
| With cooling: | No |
