Rotary viscometer RM 100 Portable
Product information "Rotary viscometer RM 100 Portable"
- 7" touch screen
- Autonomy of 1 hour
- Useable with standard stand
- Integrated temperature probe
- Printer connection
- Compatible with the RheoTex software
Scope of supply: Viscometer, carry case
| Depth: | 260 mm |
|---|---|
| Dimensions (WxDxH): | 120 x 260 x 60 mm |
| Height: | 60 mm |
| Interfaces: | RS232, USB |
| Manufacturer Article Number: | T100100 |
| Max. Viscosity: | 240000000 mPa·s |
| Max. speed: | 1500 1/min |
| Max. temperature: | 300 °C |
| Max. torque: | 30 mNm |
| Max. voltage: | 240 V·AC |
| Min. speed: | 0.3 1/min |
| Min. temperature: | -50 °C |
| Min. torque: | 0.05 mNm |
| Min. viscosity: | 200 mPa·s |
| Min. voltage: | 90 V·AC |
| Power supply: | 90 ... 240 V·AC, 50/60 Hz |
| Power supply frequency: | 50/60 Hz |
| Reproducibility: | 0,2 % |
| Speed: | 0.3 ... 1,500 1/min |
| Temperature: | -50 ... 300 °C |
| Torque: | 0.05 ... 30 mNm |
| Type: | RM 100 Portable |
| Type of auxiliary energy: | Mains connection/rechargeable battery |
| Viscosity: | 200 ... 240,000,000 mPa·s |
| Weight: | 2 kg |
| Width: | 120 mm |
Other customers also bought
For determination of the dynamic viscosity of liquids. With wide speed and torque range, integrated PT100 temperature probe and springless measuring system. Various spindles available, e.g. compatible with DIN and ASTM methods (Brookfield). Operated via a large 7" touch display. The viscometer is widely used, for example in the food, cosmetics and chemical industries.One device for the complete viscosity rangeEasy to useUnlimited number of rotation speedsDisplay of viscosity, speed, torque, time and temperatureAvailable units: P/cP, Pas/mPas or shear rateUser interface in English, French, Spanish and RussianRS 232 and USB interface for data transferPrinter connectionIntegrated user managementMethods can be programmed and stored Please order measuring spindles and accessories separately.
