Overhead stirrer RW 20 digital
Content:
1
Product number:
6227717
Product information "Overhead stirrer RW 20 digital"
- Technical improvements on the trusted RW 20 series design, mechanically controlled
- With digital display
- Robust, ergonomic design
- Constant power-drive
- Two speed ranges for universal use from 60 to 2000 rpm
- Speed range I (at 50 Hz): 60 to 500 rpm
- Speed range II (at 50 Hz): 240 to 2000 rpm
- Hollow-shafted chuck for rotor shaft height adjustment (only when stationary)
| Clamping range: | 0.5 ... 10 mm |
|---|---|
| Depth: | 212 mm |
| Dimensions (WxDxH): | 88 x 212 x 294 mm |
| Display: | Digital |
| Height: | 294 mm |
| IP code: | IP 20 |
| Manufacturer Article Number: | 0003593002 |
| Max. Viscosity: | 10000 mPa·s |
| Max. clamping width: | 10 mm |
| Max. speed: | 2000 1/min |
| Max. stirring capacity: | 20 l |
| Max. torque: | 150 Ncm |
| Max. voltage: | 230 V |
| Min. clamping width: | 0.5 mm |
| Min. speed: | 60 1/min |
| Plug type: | UK |
| Power supply: | 230 V, 50/60 Hz |
| Power supply frequency: | 50/60 Hz |
| Rated capacity: | 72 W |
| Speed: | 60 ... 2,000 1/min |
| Type: | RW 20 digital S2 |
| Type of auxiliary energy: | Mains connection |
| UNSPSC: | 41-10-38-10 |
| Weight: | 3.1 kg |
| Width: | 88 mm |
| With timer: | No |
Skip product gallery
Accessories
Plate stands for overhead stirrers and Dispersers T 18 and T 25
Plate stands with slip resistant foil. Max. load 5 kg.
Bossheads R 182 for overhead stirrers and Dispersers T 18 and T 25
Claming range stand/extension arm 6 to 16 mm.
