Laboratory presses MP150
Product information "Laboratory presses MP150"
- Manual valve for controlled pressure reduction
- Keeps pressure stable for several hours
- Integrated splinter protection
- Integrated pressure control valve
- Press dies are available from 3 to 50 mm (optionally)
- With connection for Vacuum pump
| Cylinder Ø: | 105 mm |
|---|---|
| Depth: | 400 mm |
| Dimensions (WxDxH): | 360 x 400 x 497 mm |
| Display: | Analogue |
| Height: | 497 mm |
| Manufacturer Article Number: | 54MP150 |
| Max. clearance height: | 142 mm |
| Max. pressure: | 15 t |
| Min. pressure: | 1 t |
| Pressure: | 1 ... 15 t |
| Resolution: | 0.5 t |
| Type: | MP150 |
| UNSPSC: | 41101707 |
| Weight: | 43 kg |
| Width: | 360 mm |
Other customers also bought
The laboratory presses are available as analogue models with pressure gauge or as digital models with digital pressure display.Manual valve for controlled pressure reductionKeeps pressure stable for several hoursIntegrated splinter protectionIntegrated pressure control valvePress dies are available from 3 to 50 mm (optionally)With connection for Vacuum pumpThe laboratory presses, with pressure gauge, are used in RFA analysis to form tablets with a diameter of 32 mm or 40 mm.
Accessories
The 13 mm press die is supplied in a wooden box (for 32 and 40 mm: optional)The 32 and 40 mm press die can be combined to save costs, since the same parts can be usedAll press dies from 10 mm have a vacuum connection with a special self-locking tubing adapter, which makes it easier to connect and disconnectFurther diameters available on request.
