Inverted Microscope for advanced applications series AE31E, Binocular
Product information "Inverted Microscope for advanced applications series AE31E, Binocular"
Professional inverted research microscope for a wide range of applications.
Scope of supply: microscope, Ø 45 mm blue, green interference and ground glass filters, centering telescope, power cord, Allen hexagonal key, vinyl dust cover
- Observation Tube Siedentopf Type
- Wide-field eyepieces, incl. eyecups
- Diopter adjustment on both eyepieces
- Side facing nosepiece
- Objectives CCIS® Plan achromat 4x, Ph10x, LWD Ph20x, LWD Ph40x
- Plain stage, with metal & glass stage inserts
- Condensor with phase slider (Ph1, BF)
- Illumination: Externally mounted lamp house, Koehler 6 V/30 W Quartz halogen with intensity control, automatic light switch-off
| Condenser: | ELWD N.A. 0.30 |
|---|---|
| Depth: | 556 mm |
| Depth stage: | 239 mm |
| Dimensions (WxDxH): | 200 x 556 x 529 mm |
| Height: | 529 mm |
| Inclination angle tube: | 45° |
| Interpupillary distance: | 48 ... 75 mm |
| Light type: | Halogen |
| Magnification eyepieces: | WF10x/22 mm |
| Magnification objectives: | 4x, 10x, 20x, 40x |
| Manufacturer Article Number: | 1100100200565 |
| Max. interpupillary distance: | 75 mm |
| Max. voltage: | 240 V |
| Min. interpupillary distance: | 48 mm |
| Min. voltage: | 100 V |
| Power supply: | 100 ... 240 V |
| Revolving nosepiece: | 5-fold |
| Stage (WxD): | 200 x 239 mm |
| Tube: | Binocular |
| Type of auxiliary energy: | Mains connection |
| Type of illumination (Microscopy): | Transmitted light |
| Weight: | 11.7 kg |
| Width: | 200 mm |
| Width stage: | 200 mm |
