IDS conductivity cell probes TetraCon® 925
Product information "IDS conductivity cell probes TetraCon® 925"
For connection to WTW IDS measuring instruments.
IDS conductivity cell probe TetraCon® 925 (/P):
Intelligent digital 4-pole cell with integral temperature sensor. Automatical transfer of the cell constant. Sensor head made of POM.
IDS conductivity cell probe TetraCon® 925/C:
Intelligent digital 4-pole cell with integral temperature sensor. Automatical transfer of the cell constant. Sensor head made of PEEK.
IDS conductivity cell probe TetraCon® 925/LV (/P):
Intelligent digital 4-pole cell with integral temperature sensor. Fork design, suitable for small volumes (at least 2.5 ml) as well as for viscous samples. Automatical transfer of the cell constant.
IDS conductivity cell probe TetraCon® 925 (/P):
Intelligent digital 4-pole cell with integral temperature sensor. Automatical transfer of the cell constant. Sensor head made of POM.
IDS conductivity cell probe TetraCon® 925/C:
Intelligent digital 4-pole cell with integral temperature sensor. Automatical transfer of the cell constant. Sensor head made of PEEK.
IDS conductivity cell probe TetraCon® 925/LV (/P):
Intelligent digital 4-pole cell with integral temperature sensor. Fork design, suitable for small volumes (at least 2.5 ml) as well as for viscous samples. Automatical transfer of the cell constant.
| Cable length: | 1.5 m |
|---|---|
| Cell constant: | 0.475 1/cm |
| Conductivity: | 1 µS/cm ... 2 S/cm |
| Connection plug: | Digital |
| Manufacturer Article Number: | 301710 |
| Material shaft: | Epoxy |
| Max. pressure: | 2.5 bar |
| Max. temperature: | 100 °C |
| Min. temperature: | 0 °C |
| Shaft length: | 120 mm |
| Shaft Ø: | 15.3 mm |
| Temperature: | 0 ... 100 °C |
| Temperature sensor: | NTC 30 kOhm |
| Type: | TetraCon® 925 |
