Carbon Dioxide Safety Monitor AX60
Content:
1
Product number:
6284262
Product information "Carbon Dioxide Safety Monitor AX60"
Gas warning device for precise measurement of the amount of CO2 in the air. 3 alarm settings factory set: Time-weighted average (TWA) alarm (5000 ppm; 0.5% CO2), Low alarm (15,000 ppm; 1.5% CO2) and High alarm (30,000 ppm; 3% CO2)
Scope of delivery: wall-mounted central display unit, CO2 sensor and CO2 alarm which can provide an early warning of a CO2 leak.
- No calibration required (unless local regulations state otherwise)
- Very long life sensor can last up to 15 years
- Up to 4 x CO2sensors and 8 x CO2 alarms can be used per Central Display Unit
- Supplied with a relay on each alarm which can be used to trigger ventilation, extraction or a building management system
- Easy installation and maintenance can be conducted by the user
- Additional (quick connect) CO2 sensors and alarms available if more than one entrance to the laboratory or more than one risk area
- Assists in compliance with Exposure Limit regulations such as EH40
Scope of delivery: wall-mounted central display unit, CO2 sensor and CO2 alarm which can provide an early warning of a CO2 leak.
| Depth: | 110 mm |
|---|---|
| Dimensions (WxDxH): | 175 x 110 x 75 mm |
| For: | 0,1 ... 5 % CO﹤sub﹥2﹤/sub﹥ |
| Height: | 75 mm |
| IP code: | IP 55 |
| Manufacturer Article Number: | AP1 |
| No. of gases: | 1 |
| Type: | AX60 |
| Type of auxiliary energy: | Mains connection |
| Warranty: | 5 years |
| Width: | 175 mm |
| With alarm: | Yes |
