Carbon Dioxide Safety Monitor AX60
Content:
1
Product number:
6284264
Product information "Carbon Dioxide Safety Monitor AX60"
Gas warning device for precise measurement of the amount of CO2 in the air. 3 alarm settings factory set: Time-weighted average (TWA) alarm (5000 ppm; 0.5% CO2), Low alarm (15,000 ppm; 1.5% CO2) and High alarm (30,000 ppm; 3% CO2)
Scope of delivery: wall-mounted central display unit, CO2 sensor and CO2 alarm which can provide an early warning of a CO2 leak.
- No calibration required (unless local regulations state otherwise)
- Very long life sensor can last up to 15 years
- Up to 4 x CO2sensors and 8 x CO2 alarms can be used per Central Display Unit
- Supplied with a relay on each alarm which can be used to trigger ventilation, extraction or a building management system
- Easy installation and maintenance can be conducted by the user
- Additional (quick connect) CO2 sensors and alarms available if more than one entrance to the laboratory or more than one risk area
- Assists in compliance with Exposure Limit regulations such as EH40
Scope of delivery: wall-mounted central display unit, CO2 sensor and CO2 alarm which can provide an early warning of a CO2 leak.
| Specifications: | |
| Range : Accuracy : | 0.1 to 5 % CO2 +/- 5 % of alarm setpoint |
| Alarm intensity : | 88 dbA |
| Monitor Display : | 16 digit 2 line LCD in ppm |
| TWA Alarm : | 5,000 ppm (0.5 %) over 8 hours |
| CO2 Alarms : | 15,000 ppm (1.5 %) and 30,000 ppm (3 %) |
| Operating Temperature : | -5 to 50 °C |
| Central Unit Dimensions : | 175 x 110 x 75 mm |
| Sensor & Alarm Dimensions : | 72 x 170 x 45 mm |
| IP Rating : | IP55 (IP54 Central Display Unit) |
| Warranty : | 5 years for electronics and sensor |
| Description: | Additional CO2 Alarm (Max 8 per Central Display Unit) |
|---|---|
| Manufacturer Article Number: | AX60RQYBA |
