Binocular Microscopes for Schools/Laboratories B1-220E-SP
Content:
1
Product number:
6284968
Product information "Binocular Microscopes for Schools/Laboratories B1-220E-SP"
Established Quality with a new design. The B1 series covers a wide range of the daily work for Laboratory and University use. The Elite Series with improved optics and mechanics enables efficient work for many years.
- Observation Tube Binocular 45° / Phototube 30°, 360° rotating
- Widefield eyepieces WF10X/18 mm
- Quadruple revolving nosepiece
- Semi-Plan objectives SP 4X, 10X, 40X S, 100X S-Oil
- Coaxial coarse and fine focusing system with tension adjustment
- Built-in low position coaxial rackless mechanical stage
- Focusable 1.25 N.A. Abbe condenser with iris diaphragm
- LED illumination 3 W with intensity control
- Power supply 100-240 V
- Dust cover and immersion oil
| Condenser: | Abbe 1,25 |
|---|---|
| Depth: | 245 mm |
| Dimensions (WxDxH): | 190 x 245 x 380 mm |
| Height: | 380 mm |
| Inclination angle tube: | 45° |
| Light type: | LED |
| Magnification objectives: | 4x, 10x, 40x, 100x |
| Manufacturer Article Number: | 1100100501152 |
| Max. voltage: | 240 V |
| Min. voltage: | 100 V |
| Power supply: | 100 ... 240 V |
| Revolving nosepiece: | 4-fold |
| Tube: | Binocular |
| Type: | B1-220E-SP |
| Type of auxiliary energy: | Mains connection |
| Weight: | 6.8 kg |
| Width: | 190 mm |
