Dry Block Heaters, analogue
High wattage, constant-temperature Dry Block Heaters are economical, versatile and compact. These multi-purpose units are ideal for incubation and activation of cultures, enzyme reactions, immunoassays, melting/boiling points and a wide variety of other laboratory procedures. Each of the five models accept separate interchangeable modular blocks, accommodating various sample enclosures such as micro-tubes, centrifuge tubes, vials, microplates, and PCR strips or tubes. Each block has a thermometer well for measuring block temperature. Anodized aluminum modular blocks provide superior temperature stability and heat transfer.Microprocessor ControlAdjustment knobsWithout blocks. Please order separately.SpecificationsTemperature range lower / upper range:ambient +5 to 100 °C / 75 to 150 °CUniformity within block at 37 °C:±0.2 °CTemperature stability at 37 °C1 block:
2 blocks:
4 / 6 blocks:±1.5 °C
±2.0 °C
±2.5 °CUniformity across blocks at 37 °C / Heat up time to 100 °C:1 block:
2 blocks:
4 blocks:
6 blocks:- / 45 min
±0.1 °C / 50 min
±0.2 °C / 70 min
±0.3 °C / 75 minPermissible ambient conditions:18 to 33 °CPower supply:230 V, 50/60 Hz
Dry Block Heaters, digital
Designed for applications that require repeatable results and superior temperature stability. These multi-purpose units are ideal for incubation and activation of cultures, enzyme reactions, immunoassays, melting/boiling points, and a wide variety of other laboratory procedures. Integral support rod holder with locking knob accepts optional External Temperature Probe Kit. Optional External Temperature Probe Kit monitors actual block or sample temperature. Each of the models accept separate interchangeable modular blocks, accommodating various tube sizes from 0.2 ml microtubes to 50 ml centrifuge tubes. Each block has a thermometer well for measuring block temperature. Efficient heating due to close tube-and-block contact for maximum heat retention.Microprocessor ControlLED DisplayTemperature Calibration ModeCaution Hot IndicatorAudible AlarmWithout blocks. Please order separately.SpecificationsTemperature range:
Temperature stability at 37 °C:ambient +5 to 120 °C
±0.2 °CUniformity within block at 37 °C:±0.2 °CUniformity across blocks at 37 °C / Heat up time to 100 °C1 block:
2 blocks:
4 blocks:
6 blocks:- / 45 min
±0.1 °C / 50 min
±0.2 °C / 60 min
±0.3 °C / 65 minPermissible ambient conditions:18 to 33 °CPower supply:230 V, 50/60 Hz
Dry Block Heaters, 2 blocks, with lid
The digital Dry Block Heater with Heated Lid is designed for applications that require repeatable results and superior temperature stability. These multi-purpose units are ideal for isothermal incubation, enzyme reactions, immunoassays, nucleic acid denaturation and a wide variety of other laboratory procedures. Integral support rod holder with locking knob accepts optional External Temperature Probe Kit. Optional External Temperature Probe Kit monitors actual block or sample temperature. Block heater accepts one microplate block or two separate interchangeable modular blocks, accommodating various tube sizes from 0.2 ml micro-tubes to test tubes or vials up to 85 mm in height. Each block has a thermometer well for measuring block temperature. Efficient heating due to close tube-and-block contact with a low density design for exceptional temperature uniformity. The heated lid helps to regulate the temperature and reduce the amount of condensation on sample lids.Microprocessor controlLED-DisplayTemperature Calibration ModeCaution Hot IndicatorOvershoot ProtectionAudible AlarmWithout blocks. Please order separately.SpecificationsTemperature range:
Temperature stability at 37 °C:ambient +5 to 100 °C
±0.2 °CUniformity within block at 37 °C:±0.2 °CUniformity across blocks at 37 °C±0.2 °CHeat up time to 100 °C:50 minPermissible ambient conditions:18 to 33 °CPower supply:230 V, 50/60 Hz
Temperature Probe Kit for Dry Block Heaters
Enables the unit to read actual block or sample temperature and display that temperature on the control panel. The optional External Temperature Probe Kit includes a stainless steel RTD PT100 probe, 457 mm stainless steel support rod, thermometer/temperature probe extension clamp and hook connector. The PT100 RTD probe is designed to fit perfectly in to the thermometer well of each modular block.
SmartExtender™ for Eppendorf ThermoMixer™ C and ThermoStat C
A heatable frame/attachment for mixer, with separate temperature control (3 °C above RT to 110 °C), for simultaneous operation at two different temperatures.
Dry Block Heater Matrix Δ+
Powerful Dry Block Heater for samples with very small volumes, e.g. blood samples, pharmaceutical agents, DNA/RNA samples or Elisa assays. Wide range of exchangeable attachments for various applications available.Without cross-contaminationLarge and clear display with a convenient menu structure allows for intuitive operationRobust aluminum die cast housingPlease order attachments separately.
Thermo Scientific™ Digital Dry Bath / Block Heater
Thermo Scientific™ digital dry baths, which offer a range of configurations with interchangeable modular blocks for a variety of application needs.Designed for basic to advanced applications with a max temperature of 130 °C, a timer and available in 1, 2 and 4 block sizes.Digital controls and display of time and temperatureAdvanced internal temperature sensing probe for outstanding temperature accuracy and controlPrecise temperature control with PID circuitTemperature calibration enables to offset the temperature to desired valueTimer allows the user to accurately monitor the heating timeWide range of interchangeable aluminum alloy heat blocks provide versatility and allow for easy cleaning and disinfectingPowder-coated steel body construction ensures durabilityBuilt-in over-temperature protection device warrants sample and user safetyTemperature deviation adjustmentBlocks are not included. Please order separately.Relative Humidity≤ 80%Temperature Accuracy≤ ± 0.5 °CTimer0 ... 99:59 min or continuousControllerPID digitalTemperature RangeAmbient + 5 °C – 130 °C (Ambient at 25 °C)Power supply200 ... 240 V, 50/60 Hz
Digital Dry Bath microBLOCK
Suitable to incubates PCR strips or tubes with sizes up to 50ml. The compact microBLOCK offers the smallest footprint of all digital dry baths on the market combined with a very good heating rate.Block material aluminiumExchangeable blocks, for different tube sizes from 0.2 to 50 mlTimerCompact, fits in the palm of your handClear cover ensures temperature uniformityDigital temperature controlSpecificationsTemperature Range:Ambient +5 ... 80 °COperating Temperature:5 °C ... 35 °CTemperature Accuracy:±0.5 °CTimer:0 ... 999 minDimensions (W x D x H):100 mm x 152 mm x 112 mmWeight:850 gSupply requirements:100-240 V, 50-60 Hz* Not compatible with clear cover
Exchangeable blocks Eppendorf SmartBlocks™
Flexibility has never been this easy. Eppendorf offers a variety of SmartBlocks™ for tubes from 0.5 ml to 50 ml.Fast and simple block exchange due to Eppendorf Quick ReleaseOptimized block design guarantees maximum temperature transfer to the sample
Thermo Scientific™ Digital Dry Bath / Block Heater Touch Screen
Thermo Scientific™ digital dry baths, which offer a range of configurations with interchangeable modular blocks for a variety of application needs.Designed for basic to advanced applications with a max temperature of 130 °C, a timer and available in 1, 2 and 4 block sizes.Touch screen control displays time and temperatureAdvanced internal temperature sensing probe for outstanding temperature accuracy and controlPrecise temperature control with PID circuitTemperature calibration enables to offset the temperature to desired valueTimer allows the user to accurately monitor the heating timeWide range of interchangeable aluminum alloy heat blocks provide versatility and allow for easy cleaning and disinfectingPowder-coated steel body construction ensures durabilityBuilt-in over-temperature protection device warrants sample and user safetyTemperature deviation adjustmentBlocks are not included. Please order separately.Temperature RangeAmbient + 5 °C ... 130 °C (Ambient at 25 °C)Temperature Accuracy≤ ± 0.5 °CTimer0 ... 99:59 min or continuousControllerPID digitalRelative Humidity≤ 80%Power supply200 ... 240 V, 50/60 Hz
Thermo Scientific™ Compact Digital Dry Bath/Block Heater S and D
Built-in temperature-sensing probe assists with outstanding temperature accuracy and controlDesigned for precise temperature controlFast heating rateMultiple combination of different size of blocks allows for maximum tube size versatility during experimental procedure12 V low voltage power inputModel S can hold 1 full block, 2 half blocks, 2 quarter blocks or 1 half Block and 2 quarter blocks.Model D can hold 2 full blocks, 4 half blocks, 8 quarter blocks or a combination of full/half and quarter blocks.Blocks are not included. Please order separately.Temperature RangeAmbient +2 °C ... 100 °CTemperature Accuracy at 37 °C≤ ± 0.5 °CTemperature stability at 37 °C≤ ± 0.5 °CHeating rate (30 °C to 100 °C, ambient at 25 °C, with one 0.2 ml block)16 min. // 20 min.Voltage100 ... 240 VElectrical Requirements12 V DC, 5 A // 12 V DC, 7 A
New
Dry block heater ECODRYBlock System
ECODryBlock is a digital, modular dry block heater for precise sample heating in life science applications and environmental analyses, e.g. DNA denaturation, enzymatic reactions, and COD measurements. The ControlPad can manage up to two heating modules, each with space for two aluminium blocks. Different temperatures and times can be set for each heating module.Capacitive 7" touchscreen with glass surfaceUser-friendly interface for quick parameter setting and intuitive operationHeating icon lights up when the start button is pressedHot plate icon lights up when the temperature exceeds 50 °CTimer adjustable from 1 min to 99 h 59 min2 timer settings selectable: Snap (timer countdown starts as soon as the analysis is started), Setpoint (timer countdown starts when the temperature setpoint is reached)2 thermoregulation settings selectable: Fine (optimised temperature control for minimal overshoot), Fast (fast temperature rise)Compact design saves space on the lab benchWireless connections keep the bench tidy and clutter-freeLarge selection of interchangeable aluminium blocks for different vesselsOptional lid minimises heat loss and temperature differencesOptional external probes (Pt100/Pt1000) enable direct measurement and control of the sample temperatureScope of supply: Heating module, control pad
New
Dry block heater ECODRYBlock System COD 24
ECODryBlock is a digital, modular dry block heater for precise sample heating in life science applications and environmental analyses, e.g. DNA denaturation, enzymatic reactions, and COD measurements. The ControlPad can manage up to two heating modules, each with space for two aluminium blocks. Different temperatures and times can be set for each heating module.Capacitive 7" touchscreen with glass surfaceUser-friendly interface for quick parameter setting and intuitive operationHeating icon lights up when the start button is pressedHot plate icon lights up when the temperature exceeds 50 °CTimer adjustable from 1 min to 99 h 59 min2 timer settings selectable: Snap (timer countdown starts as soon as the analysis is started), Setpoint (timer countdown starts when the temperature setpoint is reached)2 thermoregulation settings selectable: Fine (optimised temperature control for minimal overshoot), Fast (fast temperature rise)Compact design saves space on the lab benchWireless connections keep the bench tidy and clutter-freeLarge selection of interchangeable aluminium blocks for different vesselsOptional lid minimises heat loss and temperature differencesOptional external probes (Pt100/Pt1000) enable direct measurement and control of the sample temperatureScope of supply: Heating module, control pad, lid, block for 24 COD tubes (Ø 16 mm)
New
Dry block heater ECODRYBlock System COD 4
ECODryBlock is a digital, modular dry block heater for precise sample heating in life science applications and environmental analyses, e.g. DNA denaturation, enzymatic reactions, and COD measurements. The ControlPad can manage up to two heating modules, each with space for two aluminium blocks. Different temperatures and times can be set for each heating module.Capacitive 7" touchscreen with glass surfaceUser-friendly interface for quick parameter setting and intuitive operationHeating icon lights up when the start button is pressedHot plate icon lights up when the temperature exceeds 50 °CTimer adjustable from 1 min to 99 h 59 min2 timer settings selectable: Snap (timer countdown starts as soon as the analysis is started), Setpoint (timer countdown starts when the temperature setpoint is reached)2 thermoregulation settings selectable: Fine (optimised temperature control for minimal overshoot), Fast (fast temperature rise)Compact design saves space on the lab benchWireless connections keep the bench tidy and clutter-freeLarge selection of interchangeable aluminium blocks for different vesselsOptional lid minimises heat loss and temperature differencesOptional external probes (Pt100/Pt1000) enable direct measurement and control of the sample temperatureScope of supply: Heating module, control pad, block for 4 COD tubes (Ø 42 mm)
New
Dry block heater ECODRYBlock, heating module without control pad
ECODryBlock is a digital, modular dry block heater for precise sample heating in life science applications and environmental analyses, e.g. DNA denaturation, enzymatic reactions, and COD measurements. The ControlPad can manage up to two heating modules, each with space for two aluminium blocks. Different temperatures and times can be set for each heating module.Capacitive 7" touchscreen with glass surfaceUser-friendly interface for quick parameter setting and intuitive operationHeating icon lights up when the start button is pressedHot plate icon lights up when the temperature exceeds 50 °CTimer adjustable from 1 min to 99 h 59 min2 timer settings selectable: Snap (timer countdown starts as soon as the analysis is started), Setpoint (timer countdown starts when the temperature setpoint is reached)2 thermoregulation settings selectable: Fine (optimised temperature control for minimal overshoot), Fast (fast temperature rise)Compact design saves space on the lab benchWireless connections keep the bench tidy and clutter-freeLarge selection of interchangeable aluminium blocks for different vesselsOptional lid minimises heat loss and temperature differencesOptional external probes (Pt100/Pt1000) enable direct measurement and control of the sample temperatureHeating module without control pad for expanding the block thermostat system.
New
Blocks for test tubes for dry block heater ECODRYBlock
Interchangeable aluminum blocks guarentee optimal thermal conductivity, uniform heating, and easy cleaning for tempering round bottom test tubes. For general laboratory heating tasks, such as preparing solutions, dissolving substances, or incubating samples during routine chemical and biological analyses. Each block includes a dedicated hole to accommodate an external Pt100/Pt1000 temperature sensor, allowing direct monitoring and control of the actual sample temperature.
New
Blocks for microcentrifuge tubes for dry block heater ECODRYBlock
Interchangeable aluminum blocks guarentee optimal thermal conductivity, uniform heating, and easy cleaning for microcentrifuge tubes. Designed for small-volume samples typically used in molecular biology and biochemistry for the preparation and analysis of DNA, RNA, or proteins. Each block includes a dedicated hole to accommodate an external Pt100/Pt1000 temperature sensor, allowing direct monitoring and control of the actual sample temperature.
