Chemistry Pumping Units VARIO® select
Content:
1
Product number:
4662294
Product information "Chemistry Pumping Units VARIO® select"
The combination of speed controlled VARIO® chemistry diaphragm pumps and the new VACUU·SELECT vacuum controller makes the VARIO® select chemistry pumps the ideal solution for chemical processes that require precise vacuum, such as rotary evaporation, vacuum drying or vacuum concentration.
Country-specific power cord versions available on request.
- High chemical resistance and therefore ideally suited for pumping aggressive gases and vapours.
- Short process times and smooth running due to optimal setting of the pressure via the VACUU·SELECT controller.
- The VARIO® technology controls the vacuum precisely and efficiently via motor speed.
- Power consumption, maintenance and noise are exceptionally low.
- The outlet catchpot and solvent condenser combine to prevent solvent vapor emissions into the lab, allowing for nearly full recovery of solvents.
Country-specific power cord versions available on request.
| Depth: | 303 mm |
|---|---|
| Dimensions (WxDxH): | 306 x 303 x 400 mm |
| Flow rate: | 33.3 l/min |
| Height: | 400 mm |
| Manufacturer Article Number: | 20700200 |
| Plug type: | CEE |
| Type: | PC 3001 VARIO® select |
| Ultimate vacuum: | 2 mbar |
| Ultimate vacuum with gas ballast: | 4 mbar |
| Weight: | 8.2 kg |
| Width: | 306 mm |
